Used AMADA PEGA 244 Punch Press
Pre-owned AMADA PEGA 244 1991 Punch Press. This Punch Press has average cutting time and is equipped with a CNC control. This CNC Machine is currently located in USA. This AMADA Punch Press is available for a limited time. Get a quote today on this PEGA 244 before it's gone.
Specs:
Press Capacity 22 Tons
Maximum Traverse 40” X 40”
Maximum Sheet Size (with Repositioning) 40” X 100”
Maximum Hits Per Minute 350
Maximum Sheet Weight 231 LBS
Maximum Positioning Speed 2559 INCHES PER MINUTE
Total Tool Stations In Turret 44
Turret Configuration H-Type Thick Turret
18 @ 1/2" DIA
16 @ 1-1/4" DIA.
4 @ 2" DIA.
2 @ 3-1/2" DIA.
2 @ 4-1/2' DIA.
2 @ AUTO ÍNDEX (1-1/4" DIA.)
Auto Index Configuration 5.9
Angular Increment 0.01 DEGREE
Maximum Nibbling Angle
Bi -directional Rotation
AC Servo Drive 60 RPM
Turret Speed 30 RPM
Air Requirement 80 PSI
Main Motor Horsepower 5.5KW
Approx Overall Dimensions 100” W X 81’H X 198’ L
Approx Overall Weight 17,000 LBS
Maximum Traverse 40” X 40”
Maximum Sheet Size (with Repositioning) 40” X 100”
Maximum Hits Per Minute 350
Maximum Sheet Weight 231 LBS
Maximum Positioning Speed 2559 INCHES PER MINUTE
Total Tool Stations In Turret 44
Turret Configuration H-Type Thick Turret
18 @ 1/2" DIA
16 @ 1-1/4" DIA.
4 @ 2" DIA.
2 @ 3-1/2" DIA.
2 @ 4-1/2' DIA.
2 @ AUTO ÍNDEX (1-1/4" DIA.)
Auto Index Configuration 5.9
Angular Increment 0.01 DEGREE
Maximum Nibbling Angle
Bi -directional Rotation
AC Servo Drive 60 RPM
Turret Speed 30 RPM
Air Requirement 80 PSI
Main Motor Horsepower 5.5KW
Approx Overall Dimensions 100” W X 81’H X 198’ L
Approx Overall Weight 17,000 LBS
Options:
AMADAN 04P-C
Price:
$19,900
$10,500
$10,500
Payment:
Owner:
JameB765
(Machine Shop in GA)
