Used AMADA VIPROS 255 Punch Press
Pre-owned AMADA VIPROS 255 1997 Punch Press. This Punch Press has average cutting time and is equipped with a CNC control. This CNC Machine is currently located in Georgia. This AMADA Punch Press is available for a limited time. Get a quote today on this VIPROS 255 before it's gone.
Specs:
Capacity: 20 Ton
Traverse: 50” X 50”
Sheet Size (With Repositioning): 50” X 100”
Punching Capacity (Mild Steel) : 0.25”
Hits Per Minute : 1000
Sheet Weight : 220 LBS
Positioning Speed : 2,559 INCHES PER MINUTE
Tool Stations In Turret : 31
Turret Configuration: H-Type Thick Turret
36 @ 1/2" DIA
12 @ 1-1/4" DIA.
4 @ 2" DIA.
2 @ 3-1/2" DIA.
2 @ 4-1/2" DIA.
2 @ AUTO ÍNDEX (1-1/4" DIA.)
Auto Index Configuration
Angular Increment : 0.01 Degree
Maximum Nibbling Angle : 8 Degree
Indexing Station Drive : Bi-Directional Rotation
Index Drive Type: Ac Servo Drive
Index RPM: 60 RPM
Turret Index Speed : 30 RPM
Air Requirement : 80 PSI
Main Motor Horsepower : 5.5 KW
General:
Power: 220v / 3-Phase
Overall Dimensions: 205" X 123" X 97"
Weight: 21,000 lbs
Traverse: 50” X 50”
Sheet Size (With Repositioning): 50” X 100”
Punching Capacity (Mild Steel) : 0.25”
Hits Per Minute : 1000
Sheet Weight : 220 LBS
Positioning Speed : 2,559 INCHES PER MINUTE
Tool Stations In Turret : 31
Turret Configuration: H-Type Thick Turret
36 @ 1/2" DIA
12 @ 1-1/4" DIA.
4 @ 2" DIA.
2 @ 3-1/2" DIA.
2 @ 4-1/2" DIA.
2 @ AUTO ÍNDEX (1-1/4" DIA.)
Auto Index Configuration
Angular Increment : 0.01 Degree
Maximum Nibbling Angle : 8 Degree
Indexing Station Drive : Bi-Directional Rotation
Index Drive Type: Ac Servo Drive
Index RPM: 60 RPM
Turret Index Speed : 30 RPM
Air Requirement : 80 PSI
Main Motor Horsepower : 5.5 KW
General:
Power: 220v / 3-Phase
Overall Dimensions: 205" X 123" X 97"
Weight: 21,000 lbs
Price:
$29,900
$17,500
$17,500
Payment:
Owner:
MurrL507
(Machine Shop in GA)
