Seller Needs:
$12,500|
6
|
0
Pre-owned AMADA VIPROS 255 2000 Punch Press. This Punch Press has average cutting time and is equipped with a CNC control. This CNC Machine is currently located in USA. This AMADA Punch Press is available for a limited time. ...Read More
Seller Needs:
Payment:
Specs:
Capacity: 20 Ton
Traverse: 50” X 50”
Sheet Size (With Repositioning): 50” X 100”
Punching Capacity (Mild Steel) : 0.25”
Hits Per Minute: 1000
Sheet Weight: 220 LBS
Positioning Speed: 2,559" Per Minute
Tool Stations In Turret: 31
Turret Configuration: H-Type Thick Turret
36 @ 1/2" DIA
12 @ 1-1/4" DIA.
4 @ 2" DIA.
2 @ 3-1/2" DIA.
2 @ 4-1/2" DIA.
2 @ AUTO ÍNDEX (1-1/4" DIA.)
Auto Index Configuration
Angular Increment: 0.01 Degree
Maximum Nibbling Angle: 8 Degree
Indexing Station Drive: Bi-Directional Rotation
Index Drive Type: Ac Servo Drive
Index RPM: 60 RPM
Turret Index Speed: 30 RPM
Air Requirement: 80 PSI
Main Motor Horsepower: 5.5 KW
Power: 220v / 3-Phase
Dimensions: 205" x 123" x 97"
Weight: 21,000
Traverse: 50” X 50”
Sheet Size (With Repositioning): 50” X 100”
Punching Capacity (Mild Steel) : 0.25”
Hits Per Minute: 1000
Sheet Weight: 220 LBS
Positioning Speed: 2,559" Per Minute
Tool Stations In Turret: 31
Turret Configuration: H-Type Thick Turret
36 @ 1/2" DIA
12 @ 1-1/4" DIA.
4 @ 2" DIA.
2 @ 3-1/2" DIA.
2 @ 4-1/2" DIA.
2 @ AUTO ÍNDEX (1-1/4" DIA.)
Auto Index Configuration
Angular Increment: 0.01 Degree
Maximum Nibbling Angle: 8 Degree
Indexing Station Drive: Bi-Directional Rotation
Index Drive Type: Ac Servo Drive
Index RPM: 60 RPM
Turret Index Speed: 30 RPM
Air Requirement: 80 PSI
Main Motor Horsepower: 5.5 KW
Power: 220v / 3-Phase
Dimensions: 205" x 123" x 97"
Weight: 21,000
