1999 DAEWOO LYNX 200B

ID:13221
Brand:DAEWOO
Model: LYNX 200B
Year:1999
Category:CNC Lathe
Location:Wisconsin

Located In Wisconsin

SHIPPING COST :

DAEWOO LYNX 200B AI Chat

Loading ...

Machine Overview

Specs:

Daewoo Lynx 200 CNC Specifications:
Max Turning Diameter: 11.0"
Max Turning Length: 11.8"
Max Bar Capacity: 1.75"
Swing Over Bed: 18"
Distance Between Centers: 20”
X Axis Travel: 6.3"
Z Axis Travel: 13"
Rapid Traverse X Axis: 787 IPM
Rapid Traverse Z Axis: 945 IPM
Spindle Nose: A2-5
Spindle Bore: 2"
Spindle Speed: 35 – 5,000 RPM
Spindle Motor: 15 hp
Turret Capacity: 12 Stations
Turret Index Time: 0.15 Second

Equipped With:
Fanuc 21-T series CNC Control
8" 3 Jaw Kitagawa Hydraulic Chuck
Rigid Tapping
Air Blast
Tool Presetter
Parts Catcher
RS-232
Coolant System
Foot Switch
Turbo Chip Conveyor

No tooling or tool holders, but we could include extra steel chuck jaws if needed.

Options:

Fanuc
Chip Conveyor
Tool Presetter
Parts Catcher
8″ 3 Jaw Kitagawa Hydraulic Chuck
Rigid Tapping
RS-232
Coolant System
Air Blast`

Description:

Pre-owned DAEWOO PUMA 200 GL 1999 CNC Lathe. This CNC Lathe has average cutting time and is equipped with a Fanuc control. This CNC Machine is currently located in Wisconsin. This DAEWOO CNC Lathe is available for a limited time. Get a quote today on this PUMA 200 GL before it's gone.
