Machine Overview

Specs:
Turn & mill machine for 6-sided complete machining
Max. workpiece diameter
27.6 in.
Max. workpiece length
118.1 in.
Max. bar diameter
5 in.
Max. X-axis travel
31.5 in.
Max. Y-axis travel
16.5 in.
Max. Z-axis travel
120.1 in.

Integrated spindle drives with 2950.2 ft lb Nm at the main spindle for maximum cutting performance

Optional counter spindle for 6-sided complete machining with up to 2,200 Nm
Material removal rate ISM 102 to 0.1 ft3 / min (CK45)
Integrated C-axis (0.001 )
Complex turning and milling operations with an ultra-compact Turn&Mill spindle with 162.3 ft lb torque

Turning and milling spindle compactMASTER with 12,000 rpm, 48.3 hp and 162.3 ft lb - available as high-speed version with 20,000 rpm
16.5 in Y-stroke for more flexibility
Automatic tool change. 36-fold disc magazine in standard, max. 180 stations in the optional chain magazine.
Optional second tool carrier for highly productive turn & mill machining

VDI 40 turret rated at 4,000 rpm, 20.7 ft lb and 13.4 hp or VDI 40 Direct Drive turret rated at 10,000 rpm, 25.1 ft lb and 19 hp
"< 30 sec. tool set-up time and < 0.2 in repeatability with
TRIFIX precision quick-change interface as standard"
Easy to use turret steady rests and turret centers with the technology cycle (optional)

with all the bells and whistles you need
With live access movable three jaw, steady rest 80 station tool holder +6 more on opposite side low hour machine
Available now Why wait for a new one when you can save a ton of money here contact us for any additional information

Sirebuilders.com
Options:
Sub Spindle
Y Axis
5 Axis
Description:

This 2018 DMG MORI SEIKI CTX GAMMA 3000TC is a turn and mill machine designed for 6-sided complete machining tasks. It handles workpieces with a maximum diameter of 27.6 inches and can accommodate lengths of up to 118.1 inches. With a max bar diameter of 5 inches, this machine is well-suited for diverse machining needs.

The CTX GAMMA 3000TC features a generous X-axis travel of 31.5 inches, Y-axis travel of 16.5 inches, and an impressive Z-axis travel of 120.1 inches. It boasts an integrated spindle drive with 2950.2 ft lb Nm at the main spindle, providing extensive cutting performance capability. With an optional counter spindle, it offers 6-sided complete machining with up to 2,200 Nm.

The material removal rate is ISM 102 to 0.1 ft3/min, particularly for CK45 material, complemented by an integrated C-axis with 0.001 accuracy. This machine facilitates complex turning and milling operations with its ultra-compact Turn&Mill spindle that delivers 162.3 ft lb torque. For those seeking higher speeds, this machine comes with a turning and milling spindle compactMASTER offering up to 12,000 rpm and an optional high-speed version of 20,000 rpm, 48.3 hp, and 162.3 ft lb torque.

The machine's 16.5-inch Y-stroke adds flexibility, while the automatic tool change system features a 36-fold disc magazine with up to 180 stations in an optional chain magazine. It includes an optional second tool carrier for increased productivity in turn and mill machining.

It is equipped with a VDI 40 turret rated at 4,000 rpm, 20.7 ft lb, and 13.4 hp. Alternatively, choose the VDI 40 Direct Drive turret with 10,000 rpm, 25.1 ft lb, and 19 hp. With a tool set-up time of less than 30 seconds, this machine has < 0.2 in. repeatability, supported by the TRIFIX precision quick-change interface as a standard feature.

Enjoy easy-to-use turret steady rests and centers enhanced by an optional technology cycle. This machine is packed with all the features you require, including live access movable three-jaw, steady rest, and 80 station tool holder, plus an additional six on the opposite side.

With low operating hours, this machine is available now, presenting a cost-effective solution compared to purchasing new. For more details or to discuss further, please get in touch with us at Sirebuilders.com.
