Machine Overview
This 2019 DOOSAN PUMA 2600S comes with options such as a Chip Conveyor and Parts Catcher, making it a solid choice for various production needs. It is equipped with the FANUC i control system, which features an iHMi touch screen interface with a swiveling operator's panel and an Easy Operation Package.
The machine's specifications highlight its capabilities: a capacity to swing 175 mm over the bed and carriage, with the same maximum turning diameter for both the upper and lower turrets. The distance between the left and right spindle nose measures 750 mm.
The main spindle has a maximum bar capacity of 42 mm, operates at a high speed of 6,000 rpm, and is complemented with a 150 mm recommended chuck size. It features a powerful AC spindle motor with an 11 kW rating and a spindle torque rated at 116 Nm. Additionally, its C-axis offers a rapid traverse rate of 600 rpm with a minimum programmable angle of 0.001 degrees.
On the right spindle, the machine continues to perform robustly with a similar speed of 6,000 rpm and a 135 mm standard chuck size. The spindle bore diameter is measured at 53 mm and it houses an AC spindle motor rated at 11 kW, plus a maximum spindle torque of 93 Nm.
In terms of the Y-axis, the total travel is 80 mm, with 40 mm above and below center, and rapid traverse at 15 m/min. For the bed, saddle, and cross slide, the slant bed is at a 45-degree angle. This machine supports turret stations of 12 + 12 with a tool holder type of BMT-45.
Both turrets offer rotating tools with up to 6,000 rpm and a torque rating of 23.5 Nm. The coolant system includes a pump pressure of 4.5 bar, and for lubrication, the machine supports specific oils and greases for optimal operation.
Weighing in at 8,100 kg, with dimensions measuring 3,510 mm by 2,300 mm, it expands to a length of 4,455 mm with the hinge belt chip conveyor. The machine height reaches 2,070 mm with a power requirement of 52 kVA.
This model also comes equipped with several essential features, such as a Kitagawa 6" B206 3-jaw chuck, an Auto Door, Turbo chip conveyor, Robot Ethernet IP Interface, and various other enhancements to offer a comprehensive operational experience.
