Seller Needs:
$168,000|
150
|
0
This 2014 GF MIKRON XSM 600U LP Vertical Machining Center offers a comprehensive suite of features designed to enhance its operational capabilities. Included within its offering is a Probe system, ensuring precise measurement...Read More
Seller Needs:
Payment:
Specs:
X Axis Travel: 31.49"
Y Axis Travel: 23.62"
Z Axis Travel: 19.68"
Rapid Rate X Axis: 3,144 IPM
Rapid Rate Y Axis: 3,144 IPM
Rapid Rate Z Axis: 3,144 IPM
Max Table Load: 1,102 LBS
Spindle Motor: 16 HP
Spindle Speed: 36,000 RPM
Spindle Taper: HSKE50
Tool Changer: 60 ATC
Maximum tool length: 300mm
Maximum tool weight: 7kg
Table Size: 15.7" x 15.7"
Dimensions: 124" x 87" x 103"
MIKRON SHIPPING DIMENSIONS (5 PCS)
1. MAIN MACHINE UNIT 96" X 102"
2. PALLET POOL 74" X 80"
3. CHIP CONVEYOR 22" X 120"
4. CHILLER 30" X 22"
5. COOLANT/FILTRATION UNIT 34" X 74"
Y Axis Travel: 23.62"
Z Axis Travel: 19.68"
Rapid Rate X Axis: 3,144 IPM
Rapid Rate Y Axis: 3,144 IPM
Rapid Rate Z Axis: 3,144 IPM
Max Table Load: 1,102 LBS
Spindle Motor: 16 HP
Spindle Speed: 36,000 RPM
Spindle Taper: HSKE50
Tool Changer: 60 ATC
Maximum tool length: 300mm
Maximum tool weight: 7kg
Table Size: 15.7" x 15.7"
Dimensions: 124" x 87" x 103"
MIKRON SHIPPING DIMENSIONS (5 PCS)
1. MAIN MACHINE UNIT 96" X 102"
2. PALLET POOL 74" X 80"
3. CHIP CONVEYOR 22" X 120"
4. CHILLER 30" X 22"
5. COOLANT/FILTRATION UNIT 34" X 74"
Options:
Probe
Chip Conveyor
Coolant Thru Spindle
5 Axis
Heidenhain iTNC 530
20 Pallet Pool + Pallets Included
60 Tool Magazine
PFP Power Fail Protection
Kinematics Option-Touch Probe Cycles for Inspection
Paper Band Filter System
Touch Probe Infrared 40.00 TI
Prep for Touch Probe Infrared
Oil Mist Spray Unit
Oil Skimmer
Intelligent Thermal Control
Intelligent Thermal Control 5 Axis
Spindle Protection System
Laser Measurement System
Tool Blow Off Unit
Extended Accuracy 5-Axis
Temp Stabilization Unit for Coolant
Chip Conveyor
Coolant Thru Spindle
5 Axis
Heidenhain iTNC 530
20 Pallet Pool + Pallets Included
60 Tool Magazine
PFP Power Fail Protection
Kinematics Option-Touch Probe Cycles for Inspection
Paper Band Filter System
Touch Probe Infrared 40.00 TI
Prep for Touch Probe Infrared
Oil Mist Spray Unit
Oil Skimmer
Intelligent Thermal Control
Intelligent Thermal Control 5 Axis
Spindle Protection System
Laser Measurement System
Tool Blow Off Unit
Extended Accuracy 5-Axis
Temp Stabilization Unit for Coolant
Seller:
ChriL700
Location:
CA
