Machine Overview
This 2008 HAAS TL2 is a versatile used CNC lathe that's perfect for your shop needs. It comes equipped with a Tailstock, adding to its capability in handling various machining tasks. This allows the machine to assist with longer workpieces, providing support during operations.
The machine features an 8" 3 Jaw Chuck and has a maximum swing over bed of 20". Over the cross slide, the maximum swing is 11". The TL2 can handle a maximum cutting diameter of 16" and a machining length up to 48". The X-axis has a travel distance of 8", while the Z-axis can travel up to 48".
Configured with the Haas 32 BIT control, it ensures precision in machining tasks. The spindle nose is A2-6" and has a spindle bore of 2.31". The machine achieves spindle speeds of 1,800 RPM, backed by a 10 HP spindle motor. It features cross slide only turret positions, with rapid traverse rates for both axes at 450 IPM.
Included with this machine is a 10" Buck 3 Jaw Manual Chuck. The Tailstock comes fitted with a live center. For ease of use, the unit has manual hand wheels. There's a coolant system assisted by a tank and pump, an integral chip-flow channel for waste management, and a full enclosure for safety and cleanliness.
This HAAS TL2 comes with an RS 232 port interface, enabling easy data transfer. The Haas Intuitive Turning System is onboard, providing user-friendly operation guidance. It is powered via a Vector Drive Spindle and can operate on either 240V single-phase or 208V three-phase power.
The machine dimensions are 100" x 55" x 80", and it weighs 5,000 lbs. Originally used in a school setting, it has been used with care. This model could be a valuable addition to your machining capabilities, offering the features and flexibility needed for various tasks.
