X Axis Travel: 30"
Y Axis Travel: 20"
Z Axis Travel: 20"
Rapid Rate X Axis: 1,200 IPM
Rapid Rate Y Axis: 1,200 IPM
Rapid Rate Z Axis: 1,200 IPM
Max Table Load: 660 LBS
Spindle Motor: 30 HP
Spindle Speed: 15,000 RPM
Spindle Taper: 40
Tool Changer: 40+1 ATC
Dimensions: 160" x 96" x 110"
Weight: 14,250 LBS
Standard Program Memory, 1 GB Included
Dynamic Work Offsets and Tool Center Point Control Included
Early Power-Failure Detection Module Included
Ethernet Interface Included
HaasConnect: Remote monitoring Included
Second Home Position Included
High-Speed Machining Included
Media Display M-Code; M130 Included
Remote Jog Handle with Touchscreen Display Included
Rigid Tapping Included
40+1 Side-Mount Included
Top Cover with Mist Extraction Provision Included–No mist system installed
WiFi Connection for the Haas Control Included
Wireless Intuitive Probing System Included
