Table Size: 48" x 18"
Max Table Load: 1,750 LBS
X Axis Travel: 40"
Y Axis Travel: 20"
Z Axis Travel: 25"
Spindle Nose to Table: 4.2"-29.2"
Spindle Speed: 12,000 RPM
Spindle Motor: 30 HP
Spindle Taper: CAT40
Tool Changer: 24 + 1 ATC
Tool Changer Style: Sidemount
Max Tool Weight: 12 lb
Tool-to-Tool (avg): 2.8 s
Chip-to-Chip (avg): 3.6 s
EQUIPPED WITH:
Haas CNC Control
M.P.G. Manual Pulse Generator
Renishaw Table Probe and ready (less tool probe)
Programmable Coolant
Chip Auger
Control Options- Rigid tapping, Coord. Rotation & Scaling, DNC, M19 Spindle Orient, Macros, Quick code, High Speed Machining
Machine hours - 7,114 Spindle Hours
Machine is wired for 230 Volt / 3 phase / 60 HZ
Machine weight- 8000 Lbs.
Machine dimensions- 111’’ L x 91’’ W x 91’’ H
Machine location- F.O.B. Sarasota, Florida
