Table Size: 52" x 23"
Max Table Load: 1,750 LBS
X Axis Travel: 50"
Y Axis Travel: 26"
Z Axis Travel: 25"
Spindle Nose to Table 4.2" - 29.2"
Spindle Motor: 30 HP
Spindle Speed: 12,000 RPM
Spindle Taper: 40 CT
Tool Changer: 30 + 1 ATC
Equipped With:
Haas NexGen Control
W.I.P.S Probe System
WiFi Camera System for Online Monitoring
230 PSI Thru Spindle Coolant
Thru Tool Air Blast
Programmable Coolant
Remote Jog Handle with Color LCD
Chip Auger
95 Gallon Coolant tank with Auxiliary Filter System
Control Options Include: Rigid Tapping, Ethernet, Power Failure Detection Module,
WiFi, Visual Part Programming System, User Definable Macros, Additional M Functions,
Coordinate Rotation & Scaling, Spindle Orientation, Haas Window Blast, 4th Axis Pre-Wire
LESS THAN 250 SPINDLE HOURS!!!
VICES AND TOOLING IN PICTURES ARE INCLUDED!!
Dimensions: 168" x 101" x 109"
Weight: 12,700 LBS
