Pre-owned HAAS VF6-50 2019 Vertical Machining Center. This Vertical Machining Center has average cutting time and is equipped with a Haas Next Gen CNC Control control. This CNC Machine is currently located in USA. This HAAS V...Read More
Seller Needs:
Payment:
Specs:
Table Size: 64" x 28"
Max Table Load: 4,000 LBS
X Axis Travel: 64"
Y Axis Travel: 32"
Z Axis Travel: 30"
Spindle Speed: 7,500 RPM
Spindle Motor: 30 HP
Spindle Taper: CAT 50
Tool Changer: 30 + 1 ATC
Drive System: 2-Speed Gearbox
Max Tool Diameter: 4"
Max Tool Diameter: 10"
Max Tool Length: 16"
Max Tool Weight: 30 LBS.
EQUIPPED WITH:
HAAS NEXTGen Control
User Definable Macros
Coordinate Rotation & Scaling
Rigid Tap
M19 Spindle Orientation
High Speed Machining
Viisual Programming System Edit
Media Display
4th Axis Ready
1GB Memory
Comp Tables
300 PSI Thru Spindle Coolant
PLEASE NOTE: Haas HRT-450 Available for Additional Price.
Dimensions: 195" x 115" x 132"
Weight: 25,500 LBS
Max Table Load: 4,000 LBS
X Axis Travel: 64"
Y Axis Travel: 32"
Z Axis Travel: 30"
Spindle Speed: 7,500 RPM
Spindle Motor: 30 HP
Spindle Taper: CAT 50
Tool Changer: 30 + 1 ATC
Drive System: 2-Speed Gearbox
Max Tool Diameter: 4"
Max Tool Diameter: 10"
Max Tool Length: 16"
Max Tool Weight: 30 LBS.
EQUIPPED WITH:
HAAS NEXTGen Control
User Definable Macros
Coordinate Rotation & Scaling
Rigid Tap
M19 Spindle Orientation
High Speed Machining
Viisual Programming System Edit
Media Display
4th Axis Ready
1GB Memory
Comp Tables
300 PSI Thru Spindle Coolant
PLEASE NOTE: Haas HRT-450 Available for Additional Price.
Dimensions: 195" x 115" x 132"
Weight: 25,500 LBS
Options:
Haas Next Gen CNC Control
Probe
Chip Conveyor
Coolant Thru Spindle
Programmable Coolant
Probe
Chip Conveyor
Coolant Thru Spindle
Programmable Coolant
