2021 KEYENCE XM 2200

X Axis Travel: 23.63"
Y Axis Travel: 11.81"
Z Axis Travel: 7.81"
Model: XM-T 2200
Year: 2021 Image pickup device
4-megapixel CMOS image sensor
Wavelength at light receiving center
Near-infrared
Measuring range
600 mm × 300 mm × 200 mm 23.62" × 11.81" × 7.87"

Measurement accuracy
Repeatability
Stage locked: ±3 micron Stage unlocked: ±4 micron
Indication error
Probe
No. of probes 2
Stage marker No. of markers 6
Marker light source
Near-infrared LED (870 nm)
Probe connection port - 2 inputs
Console input
External remote input
Non-voltage input (contact/non-contact): 2 inputs
Interfaces
Communication (external communication)
USB 2.0 Series A: 3 ports
Ambient temperature
+10 to +35°C 50 to 95°F
Relative humidity
20 to 80% RH (no condensation)
Weight
Head: Approx. 39.6 kg (including camera and cable) Console: Approx. 150 g (including cable)
