Pre-owned MAZAK VCN410A 2012 Vertical Machining Center. This Vertical Machining Center has below average cutting time and is equipped with a Mazatrol Fusion 640T control. This CNC Machine is currently located in Milwaukee, W...Read More
Seller Needs:
Payment:
Specs:
Table Size: 35.4” X 16.1”
X-Axis Travels: 22”
Y-Axis Travels: 16”
Z-Axis Travels: 20”
Spindle Nose to Table Top: 17”
Max Table Load: 1,102 LBS
Spindle Speed: 12,000 RPM
Spindle Motor: 25HP
Spindle Taper: CAT40
Rapid Traverse: (X,Y,Z) 1417.3 IPM
ATC Positions: 30 + 1
Max Tool Diameter: 3.15”
Max Tool Diameter: (Adj Pockets) 4.92”
Max Tool Length: 13.78”
Max Tool Weight: 17.64 LBS.
Tool Change Time: Chip to Chip: 5.8 SEC
Equipped With:
MAZATROL FUSION 640M NEXUS CONTROL
ATLM
Chip Conveyor
POWER SUPPLY (15MIN/CONT) 27.8 / 22.82 kVA
MACHINE HEIGHT 110.5”
FLOOR SPACE 78.7” X 102.3”
MACHINE WEIGHT 10,824 LBS
X-Axis Travels: 22”
Y-Axis Travels: 16”
Z-Axis Travels: 20”
Spindle Nose to Table Top: 17”
Max Table Load: 1,102 LBS
Spindle Speed: 12,000 RPM
Spindle Motor: 25HP
Spindle Taper: CAT40
Rapid Traverse: (X,Y,Z) 1417.3 IPM
ATC Positions: 30 + 1
Max Tool Diameter: 3.15”
Max Tool Diameter: (Adj Pockets) 4.92”
Max Tool Length: 13.78”
Max Tool Weight: 17.64 LBS.
Tool Change Time: Chip to Chip: 5.8 SEC
Equipped With:
MAZATROL FUSION 640M NEXUS CONTROL
ATLM
Chip Conveyor
POWER SUPPLY (15MIN/CONT) 27.8 / 22.82 kVA
MACHINE HEIGHT 110.5”
FLOOR SPACE 78.7” X 102.3”
MACHINE WEIGHT 10,824 LBS
Options:
Mazatrol Fusion 640T
Chip Conveyor
Chip Conveyor
Seller:
AndyL437
Location:
IL
