MORI SEIKI MT4000 CNC Lathe

MAX CUTTING DIAMETER: 939.8 mm
MAX CUTTING LENGTH: 3,048 mm
X-AXIS TRAVEL: 1,005.8 mm
Y-AXIS: Yes
Y-AXIS TRAVEL: 11.81 (+/- 5.9")
Z-AXIS TRAVEL: 3,149.6 mm
CHUCK SIZE: 609.6 mm
SPINDLE BORE: 274.32 mm
SPINDLE NOSE: A1-20
SPINDLE MOTOR: 37.3 kW
SPINDLE SPEED: 1,000 RPM
RAPID TRAVERSE RATE - X-AXIS: 24 m/min.
RAPID TRAVERSE RATE - Y-AXIS: 24 m/min.
RAPID TRAVERSE RATE - Z-AXIS: 20 m/min.
B-AXIS SPINDLE MOTOR: 14.9 kW
B-AXIS MILLING SPEED: 6,000 RPM
B-AXIS SPINDLE TAPER: CAPTO C8
B-AXIS TOOL POSITIONS: 120
B-AXIS TRAVEL: -120 DEGREES/+105 DEGREES
Weight: 95000

COMPLETELY REBUILT MILLING SPINDLE IN 2023 ($300,000 COST)
MORI SEIKI MSX-502III CONTROL
B-AXIS MILLING SPINDLE (6,000 RPM, CAPTO C8)
Y-AXIS
50 HP TURNING SPINDLE
24", 4-JAW BISON MANUAL CHUCK
10.8" SPINDLE BORE
3000MM/120" CUTTING LENGTH
120 TOOL POSITIONS
ROHM SLZ-325 HYDRAULIC STEADY REST (1.5" 9.4" CAPACITY)
LONG BORING BAR ATTACHMENT (NEEDS REALIGNMENT)
TAILSTOCK
CHIP CONVEYOR
COOLJET HIGH-PRESSURE COOLANT UNIT (1,000 PSI)
ROYAL MIST COLLECTOR (FX1200)** MACHINE CUT PRIMARILY 4140 STEEL
** FULL REPLACEMENT COST, AS EQUIPPED - $1,000,000+
** IN PLANT, UNDER POWER, AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE** SPINDLE WAS SENT TO JAPAN & COMPLETELY REBUILT IN 2023 ($300,000 REPAIR)
** LONG BORING BAR ATTACHMENT NEEDS TO BE REALIGNED IN ORDER TO FUNCTION
** THE MACHINE HAS ISSUES WHEN DOING WRAP MILLING. IT CANNOT MAINTAIN TOLERANCES LESS THAN .02".
** HOWEVER, THE MILLING IS FULLY FUNCTIONAL & CAN HIT .002" TOLERANCE WITH THE C-AXIS BRAKE ENGAGED

MSX-502III
Chip Conveyor
Tailstock
Live Tooling
Y Axis
5 Axis
MORI SEIKI MT4000C/3000
B-AXIS MILLING SPINDLE (6,000 RPM, CAPTO C8)
120 TOOL POSITIONS
HIGH-PRESSURE COOLANT UNIT (1,000 PSI)
ROYAL MIST COLLECTOR (FX1200)
