Machine Overview

Specs:
Bar Capacity: 3.18"
Chuck Size: 10"
Spindle Speed: 4,200 RPM
Spindle Motor: 40 HP
X Axis Travel: 10.24"
Z Axis Travel: 39.76"
Turret Tools: 12 Station
Max Turning Dia: 13.39"
Max Turning Length: 31.5"
Max Swing: 22.83"
Spindle Bore: 3.59"
Spindle Nose: A2-8
Y Axis Travel: 4.53"
Sub Spindle Chuck Size: 6"
Sub Spindle Bore: 2.44"
Sub Spindle Motor: 15 HP
Sub Spindle Speed: 6,000 RPM
Live Milling Speed: 6,000 RPM

Weight: 15,000 LBS
Options:
Chip Conveyor
Tool Presetter
Bar Feeder
Live Tooling
Sub Spindle
Y Axis
OKUMA OSP-P300LA CONTROL
12’ FMB TURBO (8-80/4200A) MAGAZINE BAR FEEDER (2018)
10”, 3-JAW KITAGAWA (BB210) HYDRAULIC CHUCK (MAIN)
8”, 3-JAW KITAGAWA (B-208) HYDRAULIC CHUCK (SUB)
MP SYSTEMS HIGH-PRESSURE COOLANT UNIT (1,000 PSI)
BARFEED INTERFACE
ROBOT INTERFACE
AUTO DOOR
(1) RADIAL LIVE TOOL HOLDER
(1) AXIAL LIVE TOOL HOLDER
ONE-TOUCH IGF ADVANCE
SPINDLE SYNC. TAPPING
SPINDLE ORIENTATION
THREAD OVERRIDE
ARC THREAD CUT
SYNC. TAPPING
HI-G CONTROL
HOB CUTTING
CUSTOM-API
ANIMATION
HI-CUT PRO
** AS OF MARCH 2025, CUTTING TIME – 5,350 HOURS
** MACHINE CAN BE SOLD WITH OR WITHOUT THE BAR FEEDER
** MACHINE CAN BE SOLD WITH THE 3-JAW CHUCKS LISTED ABOVE OR WITH A SET OF ROYAL QG80 COLLET CHUCKS
Description:

This 2018 OKUMA LB3000MYW CNC Lathe offers a wide range of capabilities with its various options and upgrades. This machine includes a Chip Conveyor, Tool Presetter, Bar Feeder, and Live Tooling. Equipped with a Sub Spindle and Y Axis, this lathe operates with the OKUMA OSP-P300LA CONTROL system.

The lathe features a 12’ FMB TURBO (8-80/4200A) MAGAZINE BAR FEEDER from 2018, and a 10”, 3-JAW KITAGAWA (BB210) HYDRAULIC CHUCK for the main operations. It also includes an 8”, 3-JAW KITAGAWA (B-208) HYDRAULIC CHUCK for the sub spindle. For enhanced coolant distribution, the MP SYSTEMS HIGH-PRESSURE COOLANT UNIT ensures 1,000 PSI. Interaction with other systems is made possible through the barfeed interface and robot interface.

The auto door feature, paired with radial and axial live tool holders, provides versatility in operation. The advanced features of the machine include ONE-TOUCH IGF ADVANCE, SPINDLE SYNC. TAPPING, and SPINDLE ORIENTATION. Threading tasks are manageable with options such as THREAD OVERRIDE, ARC THREAD CUT, and SYNC. TAPPING. For precision tasks, the HI-G CONTROL, HOB CUTTING, and CUSTOM-API can be utilized. Visual tasks are supported by the ANIMATION feature with HI-CUT PRO capabilities.

As of March 2025, the machine has accumulated 5,350 hours of cutting time. Potential buyers have the flexibility of purchasing the machine with or without the bar feeder. Additionally, it can be sold with the 3-JAW CHUCKS mentioned or alternatively with a set of ROYAL QG80 COLLET CHUCKS.

This OKUMA CNC Lathe is currently located in Texas and is prepared for immediate deployment into a production environment. Interested parties may inquire further for additional specifications or to arrange a viewing.
