Seller Needs:
$630,000|
2971
|
2
Pre-owned OKUMA MULTUS U4000BB-BB-1SW 2022 CNC Lathe. This Multi-Axis Turning Center has Less Than 100 Spindle Hours and is equipped with an Okuma OSP 300 CNC control. This CNC Machine is currently located in Houston, T...Read More
Seller Needs:
Payment:
Specs:
Max Turning Diameter: 12.59"
Max Work Length: 78.7"
Distance Between Centers: 60"
Z-Axis Travel: 82.6"
X-Axis Travel: Upper / Lower / 27.36" / 9.25"
Y-Axis Travel: 11.81" (+5.91 / -5.91")
C-Axis: 360,000°
B-Axis: -30 / +210°
Left Spindle (BB): 3,000 RPM
Right Spindle: 3,800 RPM
Spindle Nose: A2-11 Big Bore Spindle (Left)
Spindle Bore / Bar: 4.4" / 4"
Right Spindle: Nose: A2-8
Right Spindle Bore / Bar: 3.15" / 3"
Milling Spindle Speed: 12,000 RPM
Milling Motor: 30 HP.
Upper ATC: 80 Station Option Purchased (CAPTO C6)
Lower Turret: 12 Tool Position, Static Tooling
Max Work Length: 78.7"
Distance Between Centers: 60"
Z-Axis Travel: 82.6"
X-Axis Travel: Upper / Lower / 27.36" / 9.25"
Y-Axis Travel: 11.81" (+5.91 / -5.91")
C-Axis: 360,000°
B-Axis: -30 / +210°
Left Spindle (BB): 3,000 RPM
Right Spindle: 3,800 RPM
Spindle Nose: A2-11 Big Bore Spindle (Left)
Spindle Bore / Bar: 4.4" / 4"
Right Spindle: Nose: A2-8
Right Spindle Bore / Bar: 3.15" / 3"
Milling Spindle Speed: 12,000 RPM
Milling Motor: 30 HP.
Upper ATC: 80 Station Option Purchased (CAPTO C6)
Lower Turret: 12 Tool Position, Static Tooling
Options:
OSP-300S CNC
Chip Conveyor
Tool Presetter
Live Tooling
Sub Spindle
Y Axis
5 Axis
Upper Turret 80 Position ATC w/ Barfeed Cover
Left and Right Integral Spindle, Liquid Cooled
Left Big Bore Spindle Option / Right SR-1670 Hyd Cylinder & Drawtube
Collision Avoidance System
1,000 High Pressure Coolant Upper and Lower
Steady Rest Included
Approximately 30 Pieces of Capto C6 Tooling and C4 Adaptors
Schunk THW3-315 Quick Jaw Change Chuck
Chip Conveyor
Tool Presetter
Live Tooling
Sub Spindle
Y Axis
5 Axis
Upper Turret 80 Position ATC w/ Barfeed Cover
Left and Right Integral Spindle, Liquid Cooled
Left Big Bore Spindle Option / Right SR-1670 Hyd Cylinder & Drawtube
Collision Avoidance System
1,000 High Pressure Coolant Upper and Lower
Steady Rest Included
Approximately 30 Pieces of Capto C6 Tooling and C4 Adaptors
Schunk THW3-315 Quick Jaw Change Chuck
Seller:
JdS294
Location:
TX
