X Axis Travel: 30"
Y Axis Travel: 16"
Z Axis Travel 20"
Rapid Rate Z Axis: 600 IPM
Table Size: 39 x 16
Max Table Load: 1,000 LBS
Spindle Motor: 10 HP
Spindle Speed: 10000 RPM
Spindle Taper: 40
Tool Changer: 21 ATC
Dimensions: 98x 77x 94
Weight: 8,500 LBS
Control: Fadal CNC88HS
Construction Box Way Cast iron
Remanned Machine 2026
These parts have been replaced or installed on this machine as part of the refurb New z and y axis way wipers
New X and Y Way Cover wipers
Reman X Axis Bearing Mount
New X Axis Ballscrew
New spindle motor fan,grill, and housing
Reman X Axis servo motor
New tool in out piston and o-ring
New knock out cap
New Draw bar Springs
New Spindle Motor Filtration system
Way lube pump
New X axis way lube lines rubber
New Y axis saddle supply lube line rubber
New spindle drive Belts
New Automatic tool changer retention clips
New rear cabinet boxer fan
New Z Axis Ballscrew
Reman Z axis bearing mount
New poly carb front door glass
Hi-Lo range pneumatic cylinders
Orientation pneumatic cylinder
New LCD Flat Screen monitor
Chiller pump filter
Chiller pump solid state relay
Chiller solid state relay
New Digital spindle motor encoder
New automatic tool changer drive belt
New external front mount air line /gun
New upper automatic tool changer spindle shaft bearing New lower automatic tool changer spindle shaft bearing
Z axis servo motor resolver
USB port mass storage conversion
A Axis controller card
A Axis servo amp.
Front door track rollers
Front door roller track
Air solenoid for air seal spindle
OSHA approved front door safety interlock receiver
Blue flashing/waiting - light bull
Majority of encloser sheet metal striped and powder coated
Table resurfaced
Program module updated p94.1 4-3
Updated 1090-3b keyboard interface
Calibration of. computer voltage
xyz servo amps. signal, balance, loop gain, and comp. master clock card calibrated backlash compensation
spindle driver rom and orientation calibrated
