Used HAAS VF6-40TR Vertical Machining Center
Pre-owned HAAS VF6-40TR 2014 Vertical Machining Center. This Vertical Machining Center has average cutting time and is equipped with a HAAS CNC Control control. This CNC Machine is currently located in North Carolina. This HAAS Vertical Machining Center is available for a limited time. Get a quote today on this VF6-40TR before it's gone.
Specs:
X Axis Travel: 64"
Y Axis Travel: 32"
Z Axis Travel: 30"
Rapid Rate X Axis: 540 IPM
Rapid Rate Y Axis: 600 IPM
Rapid Rate Z Axis: 600 IPM
Table Size: 12.2" x 12.2" Plater
Max Table Load: 500 LBS
Spindle Motor: 30 HP
Spindle Speed: 15,000 RPM
Spindle Taper: 40 CT
Tool Changer: 24 ATC
Max Cutting 500ipm
Max Tool Diameter 2.5'
Max Tool Diameter 5"
Max Tool Length 16"
Max Tool Weight 12"
Tool-to-Tool (avg) 2.8 s
Chip-to-Chip (avg) 3.6 s
A Axis - Tilt ± 120 °
B Axis - Rotation 360 °
Max Weight on Platter 500 lb
Max Part Swing 31"
Rapids on A 50 °/sec
Rapids on B 50 °/sec
Max Cutting A 33 °/sec
Max Cutting B 33 °/sec
Dimensions: 195" x 102" x 135"
Weight: 26,100 LBS
100% Aerospace Machining in 7050-T7451 Aluminum
Y Axis Travel: 32"
Z Axis Travel: 30"
Rapid Rate X Axis: 540 IPM
Rapid Rate Y Axis: 600 IPM
Rapid Rate Z Axis: 600 IPM
Table Size: 12.2" x 12.2" Plater
Max Table Load: 500 LBS
Spindle Motor: 30 HP
Spindle Speed: 15,000 RPM
Spindle Taper: 40 CT
Tool Changer: 24 ATC
Max Cutting 500ipm
Max Tool Diameter 2.5'
Max Tool Diameter 5"
Max Tool Length 16"
Max Tool Weight 12"
Tool-to-Tool (avg) 2.8 s
Chip-to-Chip (avg) 3.6 s
A Axis - Tilt ± 120 °
B Axis - Rotation 360 °
Max Weight on Platter 500 lb
Max Part Swing 31"
Rapids on A 50 °/sec
Rapids on B 50 °/sec
Max Cutting A 33 °/sec
Max Cutting B 33 °/sec
Dimensions: 195" x 102" x 135"
Weight: 26,100 LBS
100% Aerospace Machining in 7050-T7451 Aluminum
Options:
HAAS CNC Control
Probe
Programmable Coolant
5 Axis
15,000 RPM Cat 40 Upgrade
TR310 5 Axis Trunnion
8" Probe Riser
40+1 Side Mount ATC
High Speed Machining
Early power Failure Detection
Probe
Programmable Coolant
5 Axis
15,000 RPM Cat 40 Upgrade
TR310 5 Axis Trunnion
8" Probe Riser
40+1 Side Mount ATC
High Speed Machining
Early power Failure Detection
Owner:
Ian (Machine Shop in USA)
