Seller Needs:
$899,000|
172
|
0
This 2017 OKUMA MU8000VL Vertical Machining Center is a versatile and feature-rich machine designed for heavy-duty operations and precision tasks. It is equipped with a 5-axis setup and the Okuma OSP-P3005A-H Control system, ...Read More
Seller Needs:
Payment:
Specs:
X Axis Travel: 39.37"
Y Axis Travel: 21.65"
Z Axis Travel: 23.62"
Spindle Motor: 22 HP
Spindle Speed: 15,000 RPM
Spindle Taper: HSK100
Tool Changer: 48 ATC
Rapid Rate X Axis: 1,968 IPM
Rapid Rate Y Axis: 1,968 IPM
Rapid Rate Z Axis: 1,968 IPM
A Axis Travel: +90 to -90 (degrees)
C Axis Travel: 360 (degrees)
Table Surface to Spindle Nose: 7.87" to 31.50"
Max Work Size: 39.37" x 21.65"
Floor to Table Top: 47.64"
Max Tool Diameter: 3.94"/5.98"
Max Tool Length: 15.75"
Max Tool Weight: 26.4 LBS
Table Size: 31.5" x 24.8"
Dimensions: 208" x 118" x 143"
Weight: 36,900 LBS
Max Table Load: 1,540 LBS
Y Axis Travel: 21.65"
Z Axis Travel: 23.62"
Spindle Motor: 22 HP
Spindle Speed: 15,000 RPM
Spindle Taper: HSK100
Tool Changer: 48 ATC
Rapid Rate X Axis: 1,968 IPM
Rapid Rate Y Axis: 1,968 IPM
Rapid Rate Z Axis: 1,968 IPM
A Axis Travel: +90 to -90 (degrees)
C Axis Travel: 360 (degrees)
Table Surface to Spindle Nose: 7.87" to 31.50"
Max Work Size: 39.37" x 21.65"
Floor to Table Top: 47.64"
Max Tool Diameter: 3.94"/5.98"
Max Tool Length: 15.75"
Max Tool Weight: 26.4 LBS
Table Size: 31.5" x 24.8"
Dimensions: 208" x 118" x 143"
Weight: 36,900 LBS
Max Table Load: 1,540 LBS
Options:
Probe
5 Axis
Okuma OSP-P3005A-H Control
15,000 RPM Spindle
HSK A100 Spindle
Side Mount 48 ATC
Blum Tool Break detection
Auto Gauging
Gear Cutting Pkg
Laser Oscillation Device 4KW – TruDisk 4002
Powder Nozzles, Powder Feed unit, Powder Conveyor
Chiller for Laser Oscillation Device
Dust Proof for Axis
Dynamic Fixture Offset
Riedel Chiller & Dust Collection
Chip Conveyor with Right Side Disposal
**Machine can be used with or without Laser device**
5 Axis
Okuma OSP-P3005A-H Control
15,000 RPM Spindle
HSK A100 Spindle
Side Mount 48 ATC
Blum Tool Break detection
Auto Gauging
Gear Cutting Pkg
Laser Oscillation Device 4KW – TruDisk 4002
Powder Nozzles, Powder Feed unit, Powder Conveyor
Chiller for Laser Oscillation Device
Dust Proof for Axis
Dynamic Fixture Offset
Riedel Chiller & Dust Collection
Chip Conveyor with Right Side Disposal
**Machine can be used with or without Laser device**
