Pre-owned DMG Mori Dura 5100 Vertical Machining Center. This Vertical Machining Center has average cutting time and is equipped with a CNC control. This CNC Machine is currently located in Tennessee. This DMG Mori Verti...Read More
Notify Me:
Specs:
X Axis Travel: 41.3"
Y Axis Travel: 20.9"
Z Axis Travel: 20.1"
Rapid Rate X Axis: 11,811 IPM
Rapid Rate Y Axis: 11,811 IPM
Rapid Rate Z Axis: 11,811 IPM
Table Size: 53.1x23.6
Max Table Load: 2,200 LBS
Spindle Motor: 20 HP
Spindle Speed: 10,000 RPM
Spindle Taper: 40 CT
Tool Changer: 30 ATC
Dimensions: 132" x 95" x 105"
Weight: 16,000 LBS
Y Axis Travel: 20.9"
Z Axis Travel: 20.1"
Rapid Rate X Axis: 11,811 IPM
Rapid Rate Y Axis: 11,811 IPM
Rapid Rate Z Axis: 11,811 IPM
Table Size: 53.1x23.6
Max Table Load: 2,200 LBS
Spindle Motor: 20 HP
Spindle Speed: 10,000 RPM
Spindle Taper: 40 CT
Tool Changer: 30 ATC
Dimensions: 132" x 95" x 105"
Weight: 16,000 LBS
Options:
4th Axis Rotary Table
