X Axis Travel: 39.37"
Y Axis Travel: 35.43"
Z Axis Travel: 39.37"
Rapid Rate X Axis: --
Rapid Rate Y Axis: --
Rapid Rate Z Axis: --
Pallet Size: 24.9 X 24.9"
Max Pallet Load: 2640 LBS
Spindle Speed: 6000 RPM
Spindle Motor: 50 HP
Spindle Taper: --
Tool Changer: --
Dimensions: 244 X 133
Weight: 57200 LBS
Spindle Center to Pallet: 1.97" - 37.40"
Spindle Nose to Table: 2.75" - 42.12"
Spindle Speed: 6,000 RPM
Spindle Drive Motor: 50 HP
Spindle Torque: 210 ft lbs
ATC Positions: 60 Positions
ATC Max Tool Dia: 5.1" (9.45")
ATC Max Tool Length: 17.72"
ATC Max Tool Weight: 55 lbs
ATC Tool Change Time: 2 Sec
