2007 TSUNGLIN TTB36BL

ID:14170
Brand:TSUNGLIN
Model: TTB36BL
Year:2007
Category:CNC Lathe
Location:Texas

Located In Texas

SHIPPING COST :

Hello!

Loading ...

Machine Overview

Specs:

Bar Capacity: 156.5 mm (6.16")
Chuck Size: 380 mm (15") hydraulic 3-jaw
Spindle Speed: 1–1,200 rpm (3-step gearbox)
Spindle Motor: 22/26 kW (30/35 hp)
X-Axis Travel: 275 + 30 mm (12.0")
Z-Axis Travel:
S36LL: 2,800 mm (110.2")
Rapid Rate – Z:
S36LL: 8 m/min
Turret Tools: 12-station servo turret; 32 mm square shank; max ID tool Ø50 mm
Rapid Rate – X: 15 m/min
Max Turning Dia.: 500 mm (19.7")
Max Turning Length:
S36LL: 3,000 mm (118.1")
Max Swing Over Bed: 780 mm (30.7")
Dimensions (W×D×H):
S36LL: 5,200 × 1,900 × 2,100 mm
Weight:
S36LL: 7,450 kg

Options:

FANUC 0i
Chip Conveyor

Description:

Pre-owned TSUNGLIN TTB36BL 2007 CNC Lathe. This CNC Lathe has average cutting time and is equipped with a CNC control. This CNC Machine is currently located in Texas. This TSUNGLIN CNC Lathe is available for a limited time. Get a quote today on this TTB36BL before it's gone.
