Used CITIZEN L20 VII 5M7 CNC Lathe
Specifications:
Bar Capacity: .75"
Chuck Size: 8"
Spindle Speed: 5,000 RPM
Spindle Motor: 6 HP
Max Turning Dia: 3/4""
Max Turning Length: 8.1""
Dimensions: 80" x 47" x 66"
Weight: 3,600 lbs LBS
Chuck Size: 8"
Spindle Speed: 5,000 RPM
Spindle Motor: 6 HP
Max Turning Dia: 3/4""
Max Turning Length: 8.1""
Dimensions: 80" x 47" x 66"
Weight: 3,600 lbs LBS
Equipped With:
Mitsubishi Meldas / CINCOM Windows Based Control
LNS Express 226 Magazine Bar Loader (12')
Custom Macro
Main Spindle C axis
(4) Live tool positions
Tool Spindle Synch Tapping Function
Tooling - many collets, guide bushings
Brookdale Double Holders
All available manuals
LNS Express 226 Magazine Bar Loader (12')
Custom Macro
Main Spindle C axis
(4) Live tool positions
Tool Spindle Synch Tapping Function
Tooling - many collets, guide bushings
Brookdale Double Holders
All available manuals
Video:
