Machine Overview
This 2019 HURCO TM8I is a versatile and feature-rich machine that offers an impressive selection of components and capabilities to enhance your machining operations.
The equipment comes with a Chip Conveyor, Tool Presetter, Tailstock, and Parts Catcher, ensuring added convenience for diverse machining tasks. These additions make the system prepared for varied and demanding projects.
This model boasts notable specifications, such as a bar capacity of 2.6 inches and a spindle speed reaching up to 4,000 RPM. The spindle motor delivers 31 horsepower, which supports challenging machining work.
With an X-axis travel of 8 inches and a Z-axis travel of 20 inches, along with rapid traverse speeds of 1,181 inches per minute on both axes, the machine is designed to handle tasks quickly and proficiently.
The turret can accommodate 12 tools, offering flexibility for complex operations. The machine allows a maximum turning diameter of 14 inches and a length of 20.6 inches, with a max swing of 20.6 inches. The distance between centers reaches 23.2 inches.
The system can achieve a maximum torque in high gear of 161.9 foot-pounds, with turret index times ranging from 0.5 to 1.5 seconds, making it quick in its tool changing ability.
The total weight of the machine is 8,708 pounds. It is equipped with the Hurco WinMax control system, enhancing its operational capabilities with intuitive control and flexibility.
Additional features packed into this setup include a mist collector and collet chuck, further showcasing the versatility and readiness of this machine in various industrial environments.
