2024 JD SQUARED XR12
- ID:15401
- Brand:JD SQUARED
- Model: XR12
- Year:2024
- Category:Plasma
- Location:Tennessee
Machine Overview
Machine type CNC rotary tube & pipe cutter
Max tube capacity 3/4" round tube up to 12" Sch. 80 pipe
Square tube capacity Up to 12" × 0.5" wall
Structural shapes Channel, angle iron, rectangle, flat stock
Max part length 24 ft standard
Machine weight 4,000 lb
X-axis travel 28.25"
Z-axis travel 11.5"
Rapid speed (X/Y) 1350 in/min
Z-axis speed 360 in/min
Positioning resolution 0.001"
Chuck 10" self-centering 4-jaw
Servo motors Yaskawa EtherCAT brushless servos
Included software MINT motion control + CAMALOT CAM
Included marking Permanent marker + air scriber
Cooling Through-tube coolant injection
Optional tooling Drill heads, router attachments, stabilizers
Base price ~$79,900 for 30' model
Notable capabilities:
Plasma cutting
Tube coping
Structural steel processing
Drill/tap prep holes
Flat material cutting
Tube marking for bend locations
Can process rotating or flat stationary parts
Pre-owned JD SQUARED XR12 2024 Plasma. This Plasma has average cutting time and is equipped with a CNC control. This CNC Machine is currently located in USA. This JD SQUARED Plasma is available for a limited time. Get a quote today on this XR12 before it's gone.
