2021 BROTHER SPEEDIO M200X3
- ID:13196
- Brand:BROTHER
- Model: SPEEDIO M200X3
- Year:2021
- Category:Vertical Machining Center
- Location:USA

Machine Overview
This 2021 BROTHER SPEEDIO M200X3 is a high-quality machine ready for use. With under 600 operation hours, it still holds its initial capabilities and features.
Among its specifications, this machine boasts a 16,000RPM with a BT-30 spindle taper. It includes a 22 station automatic tool changer and an automatic pallet changer. The machining process is supported by through spindle coolant and an efficient coolant filtration system, which are both critical during high-speed operations.
With a 31.5" x 15.7" table/pallet size, this unit ensures adequate space for various tasks. The X-Travel reaches 25.60", Y-Travel 15.70", and Z-Travel 12.00", while the rapid traverse speed is 1969 IPM, and the cutting feed rate is up to 1181 IPM. These specifications make the machine adaptable to a wide range of machining requirements.
The robust 6.8 HP spindle motor, with a spindle nose that ranges from 9.8" to 21.8" to the table top, ensures stability during operation. Tool changes are swift, with a time of 0.8 seconds and a total chip-to-chip change time of 2 seconds.
Controlled by the Brother CNC-C00 system, this machine features a color monitor with USB and Ethernet/LAN connectivity, along with a Manual Pulse Generator/Pendant for easy operation. The interface is straightforward, featuring a 12.1" Color LCD Screen with extended input/output options and spindle override capabilities.
Overall, the 2021 BROTHER SPEEDIO M200X3 remains an outstanding choice for anyone in need of a machine that combines speed, flexibility, and precision.
