Seller Needs:
$28,000|
219
|
0
Pre-owned CHEVALIER QP2026L 2012 Vertical Machining Center. This Vertical Machining Center has average cutting time and is equipped with a Fanuc OI-MD control. This CNC Machine is currently located in USA. This CHEVALIER Vertical Machining Center is available for a limited time. Get a quote today on this QP2026L before it's gone.
Seller Needs:
Payment:
Specs:
X Axis Travel: 26"
Y Axis Travel: 20"
Z Axis Travel: 20"
Spindle Motor: 15 HP
Spindle Speed: 8,000 RPM
Spindle Taper: 40
Tool Changer: 20 ATC
Rapid Rate X Axis: 787 IPM
Rapid Rate Y Axis: 787 IPM
Rapid Rate Z Axis: 787 IPM
Max. table load 550 lbs.
Spindle nose to table surface 5.9"~20.9"
Spindle center to column 14.5"
Spindle diameter #40: 2.4" / #30: 2.0"
Cutting feed (X / Y / Z) 39.3~393 ipm
Pull stud P40T-1 / P430T-1
Max. tool diameter with adjacent tool 3.1"
Max. tool length 7.9"
Max. tool weight 15.4 lbs
Y Axis Travel: 20"
Z Axis Travel: 20"
Spindle Motor: 15 HP
Spindle Speed: 8,000 RPM
Spindle Taper: 40
Tool Changer: 20 ATC
Rapid Rate X Axis: 787 IPM
Rapid Rate Y Axis: 787 IPM
Rapid Rate Z Axis: 787 IPM
Max. table load 550 lbs.
Spindle nose to table surface 5.9"~20.9"
Spindle center to column 14.5"
Spindle diameter #40: 2.4" / #30: 2.0"
Cutting feed (X / Y / Z) 39.3~393 ipm
Pull stud P40T-1 / P430T-1
Max. tool diameter with adjacent tool 3.1"
Max. tool length 7.9"
Max. tool weight 15.4 lbs
Options:
Fanuc OI-MD
Chip Conveyor
Chip Conveyor
Seller:
JimB554
Location:
USA
