Seller Needs:
$60,500|
2418
|
11
Pre-owned DAEWOO PUMA 400L 1998 CNC Lathe. This CNC Lathe has average cutting time and is equipped with a Fanuc 18T control. This CNC Machine is currently located in USA. This DAEWOO CNC Lathe is available for a limited time....Read More
Seller Needs:
Payment:
Specs:
Bar Capacity: 4.63"
Chuck Size: 18"
Spindle Speed: 2,000 RPM
Spindle Motor: 50 HP
X Axis Travel: 14.3"
Z Axis Travel: 43.5"
Turret Index (Single Step): 0.25 Seconds
Machine Dimensions (L x W x H): 153" x 85" x 90"
Machine Weight: 19,000 lbs.
Distance Between Centers: 44.1"
Max Turning Diameter (Max / Std): 21.65" / 14.96"
Max Turning Length: 41.34"
Spindle Torque: 1836 ft. lbs.
Tailstock Taper: MT#6
Weight: 19,000 LBS
Chuck Size: 18"
Spindle Speed: 2,000 RPM
Spindle Motor: 50 HP
X Axis Travel: 14.3"
Z Axis Travel: 43.5"
Turret Index (Single Step): 0.25 Seconds
Machine Dimensions (L x W x H): 153" x 85" x 90"
Machine Weight: 19,000 lbs.
Distance Between Centers: 44.1"
Max Turning Diameter (Max / Std): 21.65" / 14.96"
Max Turning Length: 41.34"
Spindle Torque: 1836 ft. lbs.
Tailstock Taper: MT#6
Weight: 19,000 LBS
Options:
Fanuc 18T
Chip Conveyor
Tool Presetter
Tailstock
SMW-Autoblock hydraulic steady rest
Chip Conveyor
Tool Presetter
Tailstock
SMW-Autoblock hydraulic steady rest
Seller:
GeneE4450
Location:
MI
