Pre-owned HAAS ST30Y 2019 CNC Lathe. This CNC Lathe has average cutting time and is equipped with a CNC control. This CNC Machine is currently located in USA. This HAAS CNC Lathe is available for a limited time. Get a quote ...Read More
Notify Me:
Specs:
Bar Capacity: 4"
Chuck Size: 12"
Spindle Speed: 3,200 RPM
Spindle Motor: 40 HP
X Axis Travel: 12.5"
Z Axis Travel: 23"
Y Axis Travel: +2, -2"
Live Tooling: 4,000RPM
Rapid Rate Z Axis: 945 IPM
Turret Tools: 12 Station
Rapid Rate X Axis: 472 IPM
Max Turning Dia: 13.75"
Max Turning Length: 23"
Max Swing: 31.75"
Max Thrust X 4100 lbf
Max Thrust Y 2300 lbf
Max Thrust Z 5100 lbf
Max Torque 425.0 ft-lbf
Spindle Nose A2-8
Dimensions: 171" x 90" x 98"
Weight: 14,300 LBS
Chuck Size: 12"
Spindle Speed: 3,200 RPM
Spindle Motor: 40 HP
X Axis Travel: 12.5"
Z Axis Travel: 23"
Y Axis Travel: +2, -2"
Live Tooling: 4,000RPM
Rapid Rate Z Axis: 945 IPM
Turret Tools: 12 Station
Rapid Rate X Axis: 472 IPM
Max Turning Dia: 13.75"
Max Turning Length: 23"
Max Swing: 31.75"
Max Thrust X 4100 lbf
Max Thrust Y 2300 lbf
Max Thrust Z 5100 lbf
Max Torque 425.0 ft-lbf
Spindle Nose A2-8
Dimensions: 171" x 90" x 98"
Weight: 14,300 LBS
Options:
HAAS CNC Control
Chip Conveyor
Tool Presetter
Bar Feeder
Parts Catcher
Live Tooling
Y Axis
5 Axis
Chip Conveyor
Tool Presetter
Bar Feeder
Parts Catcher
Live Tooling
Y Axis
5 Axis
