If you are searching for a 2008 HAAS T5C4 multi indexer, you may want to consider this particular unit located in Alabama. This machine is in good shape, having served its purpose for only one job and has been stored properly...Read More
Specs:
Tilting 4-Head 5C Indexer
With Collets
Auto Release
Max Weight on Platter 5 lbs
SPINDLE - A (TILT)
Max Speed 60 °/sec
Max Torque 210 ft-lb
Runout Max 0.5"
Backlash 30 arc-sec
Center Height 6"
Gear Ratio 90:1
Timing 2:1
Brake Torque @ 100 psi/6.9 bar
INDEXING - A (TILT)
Max Rotation/Step ± 120 °
Resolution 0.001 °
Accuracy (±) ± 15 arc-sec
Repeatability 10 arc-sec
Worm Gear Dia 6.3"
SPINDLE - B (ROTARY)
Number 4
Max Speed 200 °/sec
Max Torque 25 ft-lbf
Nose Thread 2 3/16"
Runout Max 0.0004"
Backlash 50 arc-sec
Center Height 6"
Gear Ratio 60:1
Collet Size 5C
INDEXING - B (ROTARY)
Max Rotation/Step (with rotary control) 999.999°
Resolution 0.001 °
Accuracy (±) ± 60 arc-sec
Repeatability 10 arc-sec
Worm Gear Dia 2.8"
DIMS: 47 in x 24 in x 19 in
WEIGHT 620 lbs
With Collets
Auto Release
Max Weight on Platter 5 lbs
SPINDLE - A (TILT)
Max Speed 60 °/sec
Max Torque 210 ft-lb
Runout Max 0.5"
Backlash 30 arc-sec
Center Height 6"
Gear Ratio 90:1
Timing 2:1
Brake Torque @ 100 psi/6.9 bar
INDEXING - A (TILT)
Max Rotation/Step ± 120 °
Resolution 0.001 °
Accuracy (±) ± 15 arc-sec
Repeatability 10 arc-sec
Worm Gear Dia 6.3"
SPINDLE - B (ROTARY)
Number 4
Max Speed 200 °/sec
Max Torque 25 ft-lbf
Nose Thread 2 3/16"
Runout Max 0.0004"
Backlash 50 arc-sec
Center Height 6"
Gear Ratio 60:1
Collet Size 5C
INDEXING - B (ROTARY)
Max Rotation/Step (with rotary control) 999.999°
Resolution 0.001 °
Accuracy (±) ± 60 arc-sec
Repeatability 10 arc-sec
Worm Gear Dia 2.8"
DIMS: 47 in x 24 in x 19 in
WEIGHT 620 lbs
