Haas SL30 CNC Lathe
Though there are many Haas Lathes, the used Haas SL30 is one of the most dependable brand names. The Haas SL30 (sometimes written as SL-30) was introduced in 1999 as a mid-size CNC lathe. It is part of the SL-Series line which comes in three models, the SL-20 with a 20 swing, the SL-30 with a 30 swing and the SL-40, which has a 40 swing.
%2F1734066108474-url-pix.webp&w=3840&q=75)
%2F1733629930166-url-pix.jpg&w=3840&q=75)
Used Haas SL30 For Sale
The History of Haas SL30
The Haas SL30 design was based on improvements to the HL-Series lathes and included large headstock castings with symmetric ribs for rigidity and stability, tailstock castings with a two-piece design for easy re-alignment, embedded chip trays, and higher-volume coolant tanks. The viewing window is polycarbonate. Haas SL-30 CNCs for sale features a 14.5 x 34 (max) and 30 swing. Common options include an automatic bar feeder, live tooling or the Big-Bore option. The SL-30 Big Bore lathes have a 17 max. turning diameter vs. 14.5 on the standard Haas SL-30 CNC.
Haas SL30 Specs
| Model | Swing | Power | Bar Capacity | Spindle | Chuck Size | Dimensions |
|---|---|---|---|---|---|---|
| Haas ST-30 | 30" | 30 hp | 3" | 2,000 RPM | 10" | 150 X 77 X 74 in |
| Haas ST-30T | 30" | 30 hp | 3" | 3,400 RPM | 10" | 161 X 77 X 74 in |
| Haas ST-30L | 30" | 30 hp | 3" | 3,400 RPM | 10" | 161 X 77 X 74 in |
| Haas ST-30TB | 30" | 30 hp | 3" | 3,400 RPM | 10" | 161 X 77 X 74 in |
| Haas ST-30M | 30" | 30 hp | 3" | 3,000 RPM | 10" | 151 X 77 X 74 in |
Haas SL-30 Upgrades and Features
- Programmable Hydraulic Tailstock
- High-Pressure Coolant System
- Tool Presetter
Haas SL30 Estimated New Price
- Base Price: $79,995
- With Some Options: $89,995
- Loaded with Options: $99,995
Haas SL30 History
The Haas SL30 was first introduced in the early 2000s as part of the company's goal to provide robust and cost-effective machining solutions. Over the years, it has undergone several enhancements to maintain its competitive edge in precision lathe technology.
Haas SL 30 Industries
The Haas SL30 is widely used in various industries, including automotive, aerospace, medical devices, defense, and metalworking. Its versatility and reliability make it a preferred choice for demanding machining tasks.
Haas SL30 Pros
- Cost-effective
- High precision
- Easy to use
- Reliable
Cons
- Limited advanced features
- High maintenance costs
Competitors
- Mazak QTS-350
- Okuma LB3000EX
- Doosan Puma 3100
Haas SL30 Technical Support
Haas Automation, Inc.2800 Sturgis Rd.
Oxnard, CA 93030
Phone: (805) 278-1800
