Used MAZAK INTEGREX i200S CNC Lathe
Specifications:
Bar Capacity: 2.6"
Chuck Size: 8"
Spindle Speed: 5,000 RPM
Spindle Motor: 30 HP
X Axis Travel: 24.21"
Z Axis Travel: 42.40"
Turret Tools: 36 Station
HSK 63 tool holders
Max Turning Dia: 25.9"
Max Turning Length: 39.8"
Max Swing: 25.9"
Sub Spindle
Chuck Size: 8"
Spindle Speed: 5,000 RPM
Spindle Motor: 30 HP
X Axis Travel: 24.21"
Z Axis Travel: 42.40"
Turret Tools: 36 Station
HSK 63 tool holders
Max Turning Dia: 25.9"
Max Turning Length: 39.8"
Max Swing: 25.9"
Sub Spindle
Equipped With:
Mazatrol Matrix Nexus
Chip Conveyor
Sub Spindle
Y Axis
5 Axis
Chip Conveyor
Sub Spindle
Y Axis
5 Axis
