Mollart Models, Size and Range

Drillsprint - Gundrilling

The Drillsprint series offers both light and medium-duty capabilities to cover a wide range of deep hole drilling applications. These machines support center-line drilling from Ø2mm to Ø50mm, reaching depths of up to 3,000mm. With configurations available for 1 to 8 spindles, the Drillsprint machines are versatile enough to meet diverse drilling needs. Additional features include full machine tables for offset hole drilling and various auto-loading options, from single belt to integrated robotic and gantry systems.

Typical Applications:

• Automotive
• Aerospace
• Medical
• Transmission
• Defense
• Machinery

Micro Drilling

Mollart’s micro drilling solutions include the VDM Microdrill and Microsprint machines, designed for producing holes from Ø0.5mm to Ø6mm with depths up to 300mm. These machines incorporate advanced features such as tool monitoring, specialist filtration, index pattern drilling, and multiple component fixturing with auto-loading options.

Typical Applications:

• Fuel injection
• Medical devices
• Pneumatic and hydraulic systems
• Instrumentation
• Optical components
• Welding nozzles
• Valves and connectors

Combination Prismatic 3-4-5 and 6-Axis

Mollart offers a range of 3, 4, 5, and 6-axis single and dual spindle combination gundrill and CNC machining centers. These machines provide single cycle, multi-feature machining that combines deep hole drilling with conventional milling and drilling operations.

Typical Applications:

• Energy
• Defense
• Aerospace
• Construction
• Oil and gas
• Die and mold
• Rolling mill cylinders
• Automotive

BTA Deep Hole Drilling Machines

Mollart's BTA machines are capable of drilling Ø18mm to Ø150mm from solid and counterboring up to Ø200mm. These machines support various drilling depths up to 4,000mm and can be configured for push boring, pull boring, counterboring, and trepanning.

Typical Applications:

• Energy
• Defense
• Construction
• Oil and gas
• Power generation
• Transmission
• Aerospace
• Marine
• Automotive
• Paper

Pellet Die

Mollart is the leading manufacturer of multi-hole gundrilling centers for the food and biomass pellet die industry. These machines, available in 4, 8, or 16-spindle configurations, produce thousands of holes in a single die, ranging from Ø1.5mm to Ø12mm and up to 150mm in depth.

Pellet Die Specifications:

• 16 Spindle: Ideal for high volume die production, Ø1.5mm to Ø12mm hole range, Ø500mm to Ø1,550mm die range, up to 150mm drilling depth.
• 4 and 8 Spindle: Flexible options, Ø1.5mm to Ø12mm hole range, Ø500mm to Ø1,550mm die range, up to 150mm drilling depth.
• Flat Pellet Die: Ø5mm to Ø13mm hole range, Ø1000mm to Ø1500mm flat die range, up to 150mm drilling depth, 2, 3 or 6 spindle options.

Trepanning Machines

Mollart’s trepanning machines can produce bores between Ø60mm and Ø300mm up to 1,200mm deep, creating tube sections from bar stock or billet. This process enables core recovery, providing significant savings on expensive materials. These machines also support U-drilling and spade drilling.

Historical Timeline for Mollart

1929: Foundation - Mollart Engineering is founded, starting its journey in the field of precision engineering and manufacturing.

1940s: Expansion into Deep Hole Drilling - The company begins to specialize in deep hole drilling, becoming a key player in the industry.

1950s: Innovation and Growth - Mollart introduces several innovations in deep hole drilling technology, expanding its product range and capabilities.

1960s: Global Reach - The company starts exporting its machines and technologies, establishing a global presence.

1970s: Development of Gundrilling Machines - Mollart develops its range of gundrilling machines, enhancing precision and efficiency in deep hole drilling.

1980s: Advanced Manufacturing Techniques - The introduction of advanced manufacturing techniques and CNC technology further enhances Mollart’s product offerings.

1990s: Diversification - Mollart diversifies its product range to include micro drilling and combination machining centers, catering to a broader array of industries.

2000s: Technological Advancements - Continued investment in R&D leads to the development of state-of-the-art deep hole drilling machines and systems.

2010s: Industry Leadership - Mollart solidifies its position as an industry leader with the introduction of innovative products like the CNC Pro and advanced BTA drilling machines.

2020s: Modernization and Expansion - The company modernizes its facilities and expands its product lineup, focusing on sustainability and cutting-edge technology.

Conclusion

Mollart Engineering stands out as a premier provider of deep hole drilling and engineering solutions. With an extensive range of innovative machines and a commitment to quality, Mollart caters to diverse industrial needs, ensuring precision, efficiency, and reliability in every project.
