2021 TROTEC SPEEDY 400

PLEASE NOTE: CNCMACHINES.COM DOES NOT HAVE A "SPEEDMARKER" LISTING OPTION FOR THE SPEEDMARKER SERIES LASERS, SO THIS LISTING WAS CREATED UNDER THE AVAILABLE "SPEEDY 400".

DESCRIPTION:
2021 Trotec SpeedMarker 1350, 100W MOPA w/3D Scan Head

I am the 2nd Owner of this machine. The original owner purchased this unit in 2021.

This unit was used primarily for prototyping and process development work, as well as some work with small batch production runs. Not a lot of hours were put on the machine.

STANDARD FEATURES:
-Onboard computer and control software
-100W MOPA source
-F254 Lens
-X, Y, Z-axis capabilities

INCLUDED OPTIONAL FEATURES:
-Extended table
-3D Scan Head
-Small part B-axis rotary device
-Atmos Nano fume extractor

INCLUDED NON-STANDARD FEATURES:
-A-axis capabilities (at the scan head)

PRE-PURCHASE VIEWING/DEMONSTRATION:
We can arrange a pre-purchase Meet/Facetime/Zoom/Skype meeting so that I can demonstrate the machine's functionality prior to purchase.

MANUFACTURER SPECS:
Maximum marking area: 39 x 20 in
Max. workpiece height with F = 254: 22 in
Overall dimensions (W x D x H): 51 x 52 x 80 in
Max. marking speed: 472 ips with F = 160 mm
Max. positioning speed: 472 ips with F = 160 mm
Laser power MOPA: 100 W
Laser class: 2
Weight: 580 kg
Max. loading: 50 kg

SHIPPING/FREIGHT:
LOCAL PICKUP:
Local pickups are preferred. The machine weighs approximately 1300 lbs, and requires a forklift, or pallet jack to move.

If you are able to provide your own forklift, I will come down $1,000.00 off of my asking.

LTL FREIGHT:
Available at The Buyer's cost.

Logistics costs, including packaging of the machine for transport are the responsibility of The Buyer.

LTL freight can be arranged through your carrier, or if need be, through ours. The Buyer must state how they wish to have their machine packaged, prepared, and protected for transport by one of the following methods:

1. No Pallet
2. Open Pallet w/Shrink Wrap
3. Full Enclosed Pallet

1. NO PALLET
The moving components will be secured for transport in an effort to ensure that no doors swing open to cause damage, and that the axis' and scan head do not become damaged, or misaligned.

The laser system will be picked up by the carrier, and moved/loaded by a pallet jack and/or other method of mechanical lift equipment.

Loose parts, and items that cannot be safely secured within or to the machine will be packaged in a separate box, and either dropped with a commercial carrier like UPS or FedEx, or if preferred, handed off with the LTL carrier to transport with the machine.

This option is the most cost-effective, but offers the least amount of protection.

2. OPEN PALLET W/SHRINK-WRAP
Optional, at buyer's expense. $2,000.00 Surcharge. The machine will be secured for transport on an open pallet and shrink wrapped. Some timber framing may be installed around the machine, for added support, and stability.

Loose parts, and items that cannot be safely secured within or to the machine will be packaged in a separate box, and secured to the pallet using timber framing.

This option provides less overall protection compared to a full enclosure.

3. FULL ENCLOSURE CRATES
Optional, at buyer's expense. The buyer has the option to request a full enclosure crate to maximize the protection for the machinery.

A 3rd party onsite crating company will be contacted to crate the equipment onsite prior to logistics being scheduled. Pickup and transport will be subject to additional lead time by this vendor. The charges for that service will be invoiced directly to the buyer as a "Shipping Preparation Surcharge".

A service quote will be sourced prior to committing to this option, however, anticipated estimates for 3rd party full enclosure crating of this machine should be approximately $2,500.00-$4,000.00

Loose parts, and items that cannot be safely secured within or to the machine will be packaged in a separate box, and secured to the pallet using timber framing.

If our full asking price is met, a discount off of the Shipping Preparation Surcharge will be available.

Small Rotary Tool w/Chuck
Extended Work Table
Trotec Atmos Nano Fume Extractor
