2010 WOTAN RAPID

ID:16167
Brand:WOTAN
Model: RAPID
Year:2010
Category:Boring Mill
Location:USA

Located In USA

0-500 Hours

WOTAN RAPID AI Chat

Loading ...

Machine Overview

Specs:

X Axis Travel:
Y Axis Travel:
Z Axis Travel:
W Axis Travel:
B Axis Deg:
Table Size:
Spindle Speed:
Spindle Motor:
Tool Changer:
Spindle Taper:
Dimensions:
Weight:

Technical Description:
Spindle diameter: 130 mm
Spindle taper: ISO-50
Spindle speed: 5 to 3,000 rpm
Main power: 50 HP
Longitudinal travel (X): 16,000 mm
Vertical travel (Y): 3,000 mm
RAM travel (W): 1,000 mm
Spindle travel (Z): 600 mm
RAM section: 340 x 340 mm
Approximate weight: 36,000 Kg
– Rotary table Cap. 25T 2000 x 2000 mm
– Controlled angular headstock
– Fixed table of 16,000 mm
– Tool changer

Options:

Siemens 840D
Chip Conveyor

Description:

Pre-owned WOTAN RAPID 2010 Boring Mill. This Boring Mill has 0-500 cutting time and is equipped with a Siemens 840D control. This CNC Machine is currently located in USA. This WOTAN Boring Mill is available for a limited time. Get a quote today on this RAPID before it's gone.
