2008 MAZAK INTEGREX 100IVST

Bar Capacity: 1.65"
Chuck Size: 6"
Spindle Speed: 6,000 RPM
Spindle Motor: 15 HP
X Axis Travel: 16.14"
Z Axis Travel: 31.69"
Turret Tools: 9 Station
Max Turning Dia: 21.46"
Max Turning Length: 29.65"
Max Swing: 21.46"
Max Swing using Y Axis: 16.22" - 21.46"
Max Swing Over Cross Slide: 13.86"
Max Swing over Lower Turret: 15.75"
Max Distance between Chuck Faces: 28.9"
Spindle Nose / Spindle Bore / Bar Cap: A2-5 / 2.4" / 1.65"
Spindle Index (degrees) C Axis: 0.0001 degree
Sub Spindle Nose / Bore: A2-5 / 2.4"
Sub Spindle Speed: 6,000 rpm
Sub Spindle Index: 0.001 degree
Sub Spindle HP: 10 / 15 HP AC
Upper Turret: 1 pos. w/ ATC
Magazine Capacity: 40 Positions
Rotary Tool Spindle HP: 7.5
Rotary Tool Speed: 12,000 RPM
Lower Turret: Drum Type
Lower Turret Positions: 9 Position Turret
B-Axis Travel - Pendulum Head: 225 Degrees
Y Axis Travels: +/- 2.75"
X Axis Travel: 16.14"
Z Axis Travel: 31.69"
X2 Axis Lower: 8.66"
Z2 Axis Lower: 30.71"
W Axis Travel - Sub Spindle: 31.3"
Dimensions: 122" x 92" x 84"
Weight: 18,078 LBS

Mazatrol Matrix
Chip Conveyor
Tool Presetter
Bar Feeder
Parts Catcher
Live Tooling
Sub Spindle
Y Axis
5 Axis
Y Axis
Sub Spindle
Pendulum Style B Turret
9 Station Lower Turret
C Axis 0.0001 Degree Increment
Live Milling
40 Station Tool Magizine (CAT40)
ATLM
Automatic Parts Catcher
Mayfran Chip Conveyor
EIA/ISO Input Function
Milling Spindle Synchronous Tapping
Cardbus I/F (2 Slots)
USP Port Interface
LNS Barfeeder
